Residential Energy Storage Inverter Test System Automatic Testing Machine

 Residential Energy Storage Inverter Test System / Safe, Efficient, And Highly Stable

Introduction:

     The VILVA-HC Residential Energy Storage Inverter Test System is the ultimate testing platform for grid-tied and off-grid inverters. Custom-engineered and refined for solar inverter traits, it delivers standardized testing with exceptional efficiency and broad coverage

Features:

1. The system can measure the voltage, current, power, etc. of PV, batteries, and both grid-tied and off-grid systems
2. The fan uses a small axial flow fan with characteristics such as high airflow, good heat dissipation, and low noise
3. When the load is applied, the fan starts automatically, and after unloading, the fan stops automatically after a delay
4. The system features a newly developed high-efficiency alloy resistor, which has high power density, no red-hot phenomenon, and a long service life
5. Compatible with both grid-tied and off-grid inverter testing
6. Supports A/B side alternate switching testing (saves plugging and unplugging time)
7. Uses quick connectors for easy product wiring
8. The PV source can realistically simulate various solar panel IV output characteristics
9. Equipped with a barcode scanner to quickly scan products and input the product code information for testing (optional); The test software allows editable test items, flexible adjustment of test parameters, and automatic generation of test reports
10. Integrates communication commands for testing products, parameter reading, and parameter calibration."

 Residential Energy Storage Inverter Test System Test Items:
